6G Linear Strip Light
Product Details
DLC Premium
ETL Listed
CUL Certified
5 Year Warranty
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | TS-ST6 Series |
| Wattage Options | 25W / 30W / 40W |
| Luminous Flux | 3250 – 5200 lm |
| Luminous Efficacy | 130 lm/W |
| CCT | 4000K / 5000K / 6500K |
| Viewing Angle | 120° |
| CRI (Ra) | >80 |
| Input Voltage | 120-277V / 347V |
| Power Factor | >0.9 |
| Warranty | 5 Years |
Product Overview
The 6G Linear Strip Light carries three wattage steps and three colour temperatures in one part number, so a single SKU covers 3,250 lm up to 5,200 lm.
What does the 6G Linear strip light actually put out?
Between 3,250 and 5,200 lumens, depending on which of the three wattage steps you select — 25W, 30W or 40W. That works out to roughly 130 lm/W across the range, so dropping the wattage to trim energy costs trims light, not efficiency. Colour choice is a switch position, not a separate part number: 4000K for offices and retail interiors, 5000K for neutral task light, 6500K for daylight-bright warehouse aisles.
How do you set the wattage and colour temperature?
Two selectors on the fixture, set before you hang it. One picks the wattage step, the other the colour temperature. There's no separate driver to order and no need to stock multiple part numbers to cover a mixed job — one SKU handles a whole floor of offices, corridors and back-of-house areas. Field-selectable wattage and CCT also means late layout changes don't turn your stock into the wrong fixture.
Will it run on 347V?
Yes. The driver accepts 120-277V as standard, with a 347V option for Canadian commercial and institutional buildings where 347V service is common and most imported fixtures stop at 277V. Power factor stays above 0.9 either way. That's the difference between spec'ing this strip and adding a transformer.
Where it fits, and where it doesn't
With a 120° beam angle and CRI above 80, it suits offices, workshops, corridors, stairwells, warehouses and general industrial lighting — surface mounted, suspended or on chain. It's a strip light, not a sealed triproof: for wet locations, car washes and food processing, use the 5G Vapor instead.
